Basic Info.

Drum Placement	Horizontal Boiler
Pressure	Low Pressure
Manufacturing Level	A
Burning Style	Chamber Combustion Boiler
Usage	Industrial, Power Station
Length	7600mm
Fuel Consumption	1648kg/H
Height	4000mm
Max. Transportation Weight	47 Ton
Width	3200mm
Return Water Temperature	70oc
Heat Efficiency	87%
Circle Flow	133 M³ /H
Supply Water Temperature	115oc
Rated Working Pressure	0.9MPa
Transport Package	Wood Case or Iron Frame
Specification	CE, SGS, iISO, LR, GL, BV, DNV
Trademark	Kaineng
Origin	Qingdao, China
HS Code	84021200
Production Capacity	1000PCS

Product Description

Non-standard economic applicable Marine boiler,Horizontal boiler
WZY boiler is high-performance welded horizontal threaded tube composite boiler.
Features
1 Circular furnace is the radiant heating surface of boiler; unique threaded tubes are convectional heating surface of fuel portion.
2. The heating surface of exhaust gas portion is composed with flat tubes or threaded tubes.
3. The threaded surface of flue gas side increases gas rotating flow, therefore it enhances the heat transfer coefficient.
4. Inspection holes are in front and back of the boiler (cleaning door), therefore it is easy to clean.
5. Burner is arranged at the side of boiler, so that the operation and maintenance are both convenient.
The boiler is suitable for cargo ships, general cargo ships and so on less steam consumption ships, safe and reliable, fuel saving, and well received by users.
